RADWIN5000ConfigurationGuide Release4.9.17 7‐13
HSU MonitoringandDiagnostics
Figure7‐11:HSU‐PerformanceMonitoring‐Validandinvaliddata(2of3)
Figure7‐12:HSU‐PerformanceMonitoring‐Validandinvaliddata(3of3)
TheHSUreportcontainsmanymorefieldsthanthe HBS.Hereistheirmeaning::
Table7‐3:HSUPerformanceMonitoringFields
ColumnHeading
Abbreviation
Meaning
Description
Integrity Validdataflag
Greentickforcurrentandvalid;Redcrossforinvalidated
data(Seeexamplebelow).NotethatthePerformance
Monitoringdataisnotvalidifnotallthevalueswerestore d
(e.g.,duetoclockchangeswithintheintervalorpowerup
reset)
Date&Time Timestamp
Dataarerecordedev
ery15minutes;thelast30daysof
recordingsaremaintained.Roll‐overisatmidnight
UAS
Unavailable
Seconds
Secondsinwhichtheinterfacewasoutofservice
