RADWIN5000ConfigurationGuide Release4.9.17 2‐15
UsingtheMapView RADWINManagerOverview
WehavelocatedtheentiresectortoMelbourne,Australia(vs.Figure 2‐13)inaccor‐
dancewithourRadioPlan.Thegreylinesandiconsarepre‐registeredplace‐holders
foradditionalnomadicHSUs.
YoucanmakemanuallocationadjustmentsusingtheGUI.
 TorelocateaHBSorHSUusingtheGUI:
1. Selecttheunittomovebyclickingit.Itissurroundedbyabrownboxorperimeter.
2. Mouse‐overthetopedgeoftheboxtogetacontextbuttonbarasshownin.
Figure2‐15:SelectedHBSorHSUwithcontextbuttonbar
Thefunctionsofthebuttons(fromlefttoright)areasfollows:
3. ClicktheUnlockbutton.Dragthetowericontoitsnewlocation.Youmustconfirm
thechange:
Table2‐3:UnitContextButtonbarfunctions
Button Tooltip Purpose
Center Unlock/LockItem Unlocktodragonmap,locktosecureposition
Right Zoomin
Showmorebackgrounddetail.Alsodisplaystheunit
statuswindowifnotalreadyvisible
a
a. Youcanalsozoomin/outusingthemousescrollwheel.
