P/N 016-0171-493 Rev. I 239
Console Power
Press the blue power button to power up the remote tank console.
If the console does not power up, check that all connections are secure and that the field computer is powered
on.
Note: The current program and software version numbers will be displayed while the console initializes
during power up. Have these numbers available when contacting technical support.
To shutdown the remote tank console, press and hold the blue power button for approximately 3
seconds.
Remote Tank Console Operation
The remote tank console allows the operator to prime metering rollers, adjust valve response, perform a catch
test and enter the cal weight all while observing operation of the air cart to ensure proper operation of the
OmniSeed system.
Priming
To accurately calibrate the OmniSeed system for operation, the metering rollers must be primed and the meter
RPM set prior to performing the catch test. The operator may prime the metering rollers using the remote tank
console. To prime the metering rollers:
Note: Place the weight box below the appropriate bin to avoid dumping product on the ground. The
metering rollers will not stop automatically. Do not leave the remote tank console until the process
is complete and the metering rollers have stopped rotating.
1. With the remote tank console powered up, use the Next and Prev keys to select the desired bin and press
the Enter key.
2. Press the Begin key to start the bin calibration.
