Chapter 4: Using the Chart 99
4.17 Defining how the chart windows are presented
Each chart window can be tailored to meet your particular needs. You can:
• Set the chart view for individual windows or system wide (see below).
• Change how the chart is orientated (see
page 100
).
• Change the way your chart is drawn in relation to your boat movement (see
page 101
).
Working with multiple chart views
If you have more than one chart window, you can either share the presentation or
present each window independently. The option you have chosen is indicated on the
chart status bar as LOCAL or SYSTEM. The system view is shared across networked E-
Series displays.
System chart view
When a chart application is started it defaults to system view. Any windows set to
system view will have the same presentation as other system windows for:
• Chart mode and orientation.
• Chart layers - aerial, radar, 3D locator and AIS
• Synchronization - Radar/chart and 3D/chart.
• Show/hide waypoints, routes and tracks.
•Declutter.
• Vectors.
If you change any of these options in one window, ALL system windows will update.
Local chart view
When local chart view is selected the presentation for each window is set
independently.
Defining chart window presentation
To define how the chart windows are presented:
Note:
The motion mode will be set but not synchronized across windows when the
chart view is set to system.
PRESENTATION
CHART VIEW
LOCAL SYSTEM
D6586_3
81244_4.book Page 99 Thursday, January 31, 2008 1:53 PM
