Raymarine E-Series Reference Manual

Chapter 10: Autopilot Control 219
Chapter 10:Autopilot Control
If you have a Raymarine autopilot installed, you can access some of its functions from
the E-Series display unit.
WARNING:The autopilot functions available on the E-Series display
unit do not replace the autopilot control head. You must have a pilot
control head installed before you enable or engage the autopilot.
10.1Emergency disengage
You can disable the autopilot using the power key.
1. Press and release the POWER button.
2. Press the STANDBY softkey.
This puts the autopilot into standby mode.
10.2 Enabling and engaging the autopilot
To allow the E-Series to control autopilot functions, you need to enable autopilot
control on the display unit.
With autopilot control enabled, the unit lets you engage the autopilot whenever it has
a target waypoint. You can see information for the target waypoint on the Pilot Control
pop-up.
The default autopilot setting is
disabled .
To enable autopilot control
On the E-Series display:
1. Press the MENU button to open the Setup Menu.
2. Select System Setup > System Integration > Autopilot Control >
Enabled.
3. Press the OK button.
To engage the autopilot in normal operation
When the autopilot is enabled, the unit prompts you to engage the autopilot whenever
you initiate a GOTO or FOLLOW ROUTE.
1. Select GOTO or FOLLOW ROUTE to display the Engage Pilot screen.
2. Select ENGAGE PILOT to display the Pilot Control screen.
If you press OK or CANCEL without engaging the autopilot, you go back to the
navigation screen with the autopilot disengaged.
81244_4.book Page 219 Thursday, January 31, 2008 1:53 PM
