Chapter 5: 3D Chart 121
These can be views of:
• The same area of the chart from different angles.
• Views of up to 4 different areas of the chart.
Note:
For full details of page set up and “active” windows refer to page 18.
Vessel offset
You can specify whether the boat is fixed in the centre of the window (0 offset) or
offset by 1/3 or 2/3 of the screen. If you change the offset to 1/3 or 2/3, the view
ahead of your boat will be increased.
D8252_1
Multiple 3D views
Example:
Four 3D application windows showing the same area of the chart but from 4 different angles.
D8239_1
3D VIEW
OPTIONS...
PRESENTATION…
VESSEL OFFSET
0 1/3 2/3
