Chapter 2: General Operation 19
Adjusting the display lighting
The display has two distinct color palettes, for day and night operation. You can also
manually adjust the backlight level.
Note: The display lighting is a local setting and will therefore only affect the individual
display on which you are working.
Day/night operation
To select the day/night mode of operation:
The display saves the current palette when the unit is powered off. If the palette was set
to NIGHT when it was last used, and you then power on in bright sunlight, it may be
difficult to see the screen. Reset the palette to DAY to return to normal daytime
lighting.
Backlight level
To adjust the backlight level when in day or night operation mode:
Note: The backlight level window will autohide after 3 seconds if no buttons are
pressed.
D6802-3
Toggle as required
OK
PALETTE
DAY NIGHT
D8517_1
Backlight Level
Change the level as required
OK
81244_4.book Page 19 Thursday, January 31, 2008 1:53 PM
