280 E-Series Networked Display Reference Manual
• When you use the compass bar with an active waypoint, the bearing marker is
BLUE and the active waypoint symbol indicates the bearing to your waypoint.
Turning the compass bar on and off
You turn the compass bar on and off from the data toolbar.
• Press the DATA button.
Use the DATABAR softkey to turn the compass bar on or off.
Note:
When the compass bar is displayed the transducer icons remain visible in the top-right
section of the screen.
Compass bar setup
The compass bar is set to open in heading mode. To change this setting, press the
MENU button and go to the Databar Setup menu where you can select either Heading
or COG.
Note:
If MOB is activated while the compass bar is open, the compass is replaced with the
MOB toolbar. The compass bar returns when you cancel the active MOB.
Table 18-1: DATABAR Softkey Options
ON Displays the standard databar, at the top or side of the
screen depending on your setup options.
COMPASS Replaces the standard databar with the compass bar,
displayed along the top of the screen.
OFF Removes both the databar and the compass bar from your
display.
81244_4.book Page 280 Thursday, January 31, 2008 1:53 PM
