Reer MOSAIC MI8O4C User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 25/01/2023 • Rev.43 25
English
Module MI8O4
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
NODE_SEL0
-
Node selection
Input ("type B" according to EN 61131-2 )
3
NODE_SEL1
-
Input ("type B" according to EN 61131-2 )
4
0VDC
-
0VDC power supply
-
5
OSSD1
Output
Solid State Safety Output 1
PNP active high
6
OSSD2
Output
Solid State Safety Output 2
PNP active high
7
RESTART_FBK1/
STATUS1
Input/
Output
Feedback/Restart 1
Input according to EN 61131-2
SIL 1/PL c output
PNP active high
8
RESTART_FBK2/
STATUS2
Input/
Output
Feedback/Restart 2
Input according to EN 61131-2
SIL 1/PL c output
PNP active high
9
OSSD3
Output
Solid State Safety Output 3
PNP active high
10
OSSD4
Output
Solid State Safety Output 4
PNP active high
11
RESTART_FBK3/
STATUS3
Input/
Output
Feedback/Restart 3
Input according to EN 61131-2
SIL 1/PL c output
PNP active high
12
RESTART_FBK4/
STATUS4
Input/
Output
Feedback/Restart 4
Input according to EN 61131-2
SIL 1/PL c output
PNP active high
13
OUT_TEST1
Output
Short circuit detection
output
PNP active high
14
OUT_TEST2
Output
Short circuit detection
output
PNP active high
15
OUT_TEST3
Output
Short circuit detection
output
PNP active high
16
OUT_TEST4
Output
Short circuit detection
output
PNP active high
17
INPUT1
Input
Digital input 1
Input according to EN 61131-2
18
INPUT2
Input
Digital input 2
Input according to EN 61131-2
19
INPUT3
Input
Digital input 3
Input according to EN 61131-2
20
INPUT4
Input
Digital input 4
Input according to EN 61131-2
21
INPUT5
Input
Digital input 5
Input according to EN 61131-2
22
INPUT6
Input
Digital input 6
Input according to EN 61131-2
23
INPUT7
Input
Digital input 7
Input according to EN 61131-2
24
INPUT8
Input
Digital input 8
Input according to EN 61131-2
Table 5
➔
The STATUS SIL 1/PL c outputs are shared with the FEEDBACK/RESTART inputs of the OSSDs. To
use them, the corresponding OSSD must be used with automatic reset without external feedback
monitoring. For instance, to use the STATUS1 output (Terminal 7), you must program OSSD1 with
automatic reset without K feedback monitoring.
