Reer MOSAIC MI8O4C User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
30 8540780 • 25/01/2023 • Rev.43
English
Module MR8
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
4
GND
-
0VDC power supply
-
5
OSSD1_A
Input
Control ZONE 1
PNP active high
6
OSSD1_B
Input
7
FBK_K1_K2_1_1
Output
Feedback K1K2 ZONE 1
Normally closed EDM
8
FBK_K1_K2_1_2
Output
9
A_NC1
Output
NC contact ZONE 1
Normally closed
10
B_NC1
Output
13
A_NO11
Output
NO1 contact ZONE 1
Normally opened
14
B_NO11
Output
15
A_NO12
Output
NO2 contact ZONE 1
Normally opened
16
B_NO12
Output
11
A_NC2
Output
NC contact ZONE 2
Normally closed
12
B_NC2
Output
17
OSSD2_A
Input
Control ZONE 2
PNP active high
18
OSSD2_B
Input
19
FBK_K1_K2_2_1
Output
Feedback K1K2 ZONE 2
Normally closed EDM
20
FBK_K1_K2_2_2
Output
21
A_NO21
Output
NO1 contact ZONE 2
Normally opened
22
B_NO21
Output
23
A_NO22
Output
NO2 contact ZONE 2
Normally opened
24
B_NO22
Output
25
24VDC
-
24VDC power supply
-
28
GND
-
0VDC power supply
-
29
OSSD3_A
Input
Control ZONE 3
PNP active high
30
OSSD3_B
Input
31
FBK_K1_K2_3_1
Output
Feedback K1K2 ZONE 3
Normally closed EDM
32
FBK_K1_K2_3_2
Output
33
A_NC3
Output
NC contact ZONE 3
Normally closed
34
B_NC3
Output
37
A_NO31
Output
NO1 contact ZONE 3
Normally opened
38
B_NO31
Output
39
A_NO32
Output
NO2 contact ZONE 3
Normally opened
40
B_NO32
Output
35
A_NC4
Output
NC contact ZONE 4
Normally closed
36
B_NC4
Output
41
OSSD4_A
Input
Control ZONE 4
PNP active high
42
OSSD4_B
Input
43
FBK_K1_K2_4_1
Output
Feedback K1K2 ZONE 4
Normally closed EDM
44
FBK_K1_K2_4_2
Output
45
A_NO41
Output
NO1 contact ZONE 4
Normally opened
46
B_NO41
Output
47
A_NO42
Output
NO2 contact ZONE 4
Normally opened
48
B_NO42
Output
Table 14
