Reer MOSAIC MI8O4C User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 25/01/2023 • Rev.43 35
English
Module MO4LHCS8
PIN
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
2
NODE_SEL0
Input
Node selection
Input ("type B" according to EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" according to EN 61131-2)
4
0VDC
0VDC power supply
5
REST_FBK1
Input
Feedback/Restart 1
Input (according EN 61131-2)
6
REST_FBK2
Input
Feedback/Restart 2
Input (according EN 61131-2)
7
REST_FBK3
Input
Feedback/Restart 3
Input (according EN 61131-2)
8
REST_FBK4
Input
Feedback/Restart 4
Input (according EN 61131-2)
9
OSSD1
Output
Safety Output 1
PNP active high
4 single channels (or 2 dual channels)
10
OSSD2
Output
Safety Output 2
11
OSSD3
Output
Safety Output 3
12
OSSD4
Output
Safety Output 4
13
-
-
-
14
24 VDC
24VDC power supply
-
15
-
-
-
16
-
-
-
17
OUT_STATUS1
Output
SIL 1/PL c
PNP active high
18
OUT_STATUS2
Output
SIL 1/PL c
PNP active high
19
OUT_STATUS3
Output
SIL 1/PL c
PNP active high
20
OUT_STATUS4
Output
SIL 1/PL c
PNP active high
21
OUT_STATUS5
Output
SIL 1/PL c
PNP active high
22
OUT_STATUS6
Output
SIL 1/PL c
PNP active high
23
OUT_STATUS7
Output
SIL 1/PL c
PNP active high
24
OUT_STATUS8
Output
SIL 1/PL c
PNP active high
Table 20
Modulo MA2
PIN
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24 VDC
-
24VDC power supply
-
2
NODE_SEL0
Input
Node selection
Input ("type B" according to EN 61131-2)
3
NODE_SEL1
Input
Input ("type B" according to EN 61131-2)
4
0 VDC
-
0VDC power supply
-
9
24VDC_S1
Output
Sensor 1 Connections
Isolated 24VDC power supply for sensor 1
10
IN_S1
Input
4/20mA sensor 1 Input
NEG_S1
Input
0/10V sensor 1 negative input
11
OUT_S1
Output
4/20mA sensor 1 Output
POS_S1
Input
0/10V sensor 1 positive input
12
0 VDC_S1
Output
Isolated 0VDC reference for sensor 1
13
24VDC_S2
Output
Sensor 2 Connections
Isolated 24VDC power supply for sensor 2
14
IN_S2
Input
4/20mA sensor 2 Input
NEG_S2
Input
0/10V sensor 2 negative input
15
OUT_S2
Output
4/20mA sensor 2 Output
POS_S2
Input
0/10V sensor 2 positive input
16
0 VDC_S2
Output
Isolated 0VDC reference for sensor 2
Table 21
