MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
54 8540780 • 25/01/2023 • Rev.43
Digital INPUTS (No./description)
8 / PNP active high according to EN 61131-2
INPUT FBK/RESTART (No./description)
Up to 4 / EDM control / possible Automatic
or Manual operation with RESTART button
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
SIL 1/PL c OUTPUTS (No./description)
Up to 4 / programmable - PNP active high
4 single / solid state safety outputs:
PNP active high – 400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
Connection to MOSAIC M1S,
MOSAIC M1S COM
via MSC 5-way ReeR proprietary bus
Digital INPUTS (No./description)
PNP active high according to EN 61131-2
Test OUTPUT (No./description)
4 / to check for short-circuits - overloads
Connection to MOSAIC M1 and
MOSAIC M1S, MOSAIC M1S COM
via MSC 5-way ReeR proprietary bus
Digital INPUTS (No./description)
PNP active high according to EN 61131-2
Test OUTPUT (No./description)
8 / to check for short-circuits - overloads
Connection to MOSAIC M1 and
MOSAIC M1S, MOSAIC M1S COM
via MSC 5-way ReeR proprietary bus
