Reer MOSAIC MI8O4C User Manual

MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 25/01/2023 • Rev.43 55
English
MO2 - MO4 modules
Model
MO2
MO4
PFHd (IEC 61508:2010)
4,08E-9
5,83E-9
SFF
99,8%
99,8%
Rated voltage
24VDC  20%
Dissipated power
3W max
INPUT FBK/RESTART (No./description)
2 – 4 / EDM control / possible Automatic
or Manual operation with RESTART button
SIL 1/PL c OUTPUTS (No./description)
2
4
programmable - PNP active high
OSSD (No./description)
2
4
Solid state safety outputs: PNP active high 400mA@24VDC max
Interface type C class 3 (ZVEI CB24I)
Connection to MOSAIC M1 and
MOSAIC M1S, MOSAIC M1S COM
via MSC 5-way ReeR proprietary bus
MO4L module
PFH
d
(IEC 61508:2010)
1,11E-8
SFF
99,7%
Rated voltage
24VDC  20%
Dissipated power
3W max
INPUT FBK/RESTART (No./description)
Up to 4 / EDM control / possible Automatic
or Manual operation with RESTART button
SIL 1/PL c OUTPUTS (No./description)
4 / programmable - PNP active high
OSSD (No./description)
4 single / solid state safety outputs: PNP active high –
400mA@24VDC max - Interface type C class 3 (ZVEI CB24I)
Connection to MOSAIC M1S,
MOSAIC M1S COM
via MSC 5-way ReeR proprietary bus
MOS8 – MOS16 modules
Model
MOS8
MOS16
PFH
d
(IEC 61508:2010)
4,44E-9
6,61E-9
SFF
99,6%
99,6%
Rated voltage
24VDC  20%
Dissipated power
3W max
SIL 1/PL c OUTPUTS (No./description)
8
16
programmable - PNP active high
Connection to MOSAIC M1 and MOSAIC M1S,
MOSAIC M1S COM
through 5-way MSC proprietary bus

Reer MOSAIC MI8O4C Specifications

General

Brand	Reer
Model	MOSAIC MI8O4C
Category	Controller
Language	English
