MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
60 8540780 • 25/01/2023 • Rev.43
LED INDICATORS (Normal Operation)
Master MOSAIC M1 (Figure 20)
Writing/loading/ diagram
to/from MCM card
MSD requesting connection:
internal configuration not present
MSD requesting connection:
(slave module or node number
not correct) (ref. System composition)
MSD requesting connection:
(slave module missing or not ready)
(ref. System composition)
MSD connected MOSAIC M1 stopped
Table 27 - Opening Screen
Table 28 - Dynamic Screen
ON =
MOSAIC M1
connected to PC
OFF=otherwise
ON
MASTER_ENABLE1
and MASTER_ENABLE2
active
OFF
otherwise
RED with
output OFF
GREEN with
output ON
ON
waiting for
RESTART
Flashing
NO feedback
ON
incorrect
external
connection
detected
ON =
MOSAIC M1
connected to PC
OFF=otherwise
only the number
of the INPUT with
the incorrect
connection
flashes
