The STATUS SIL 1/PL c signal outputs are shared with the FEEDBACK/RESTART inputs of the
OSSDs. To use them, the corresponding OSSD must be used with automatic reset without
external feedback monitoring.
Module MR2
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
4
0VDC
-
0VDC power supply
-
5
OSSD1_A
Input
Control ZONE 1
PNP active high
6
OSSD1_B
Input
7
FBK_K1_K2_1
Output
Feedback K1K2 ZONE 1
9
A_NC1
Output
NC contact ZONE 1
10
B_NC1
Output
13
A_NO11
Output
NO1 contact ZONE 1
14
B_NO11
Output
15
A_NO12
Output
NO2 contact ZONE 1
16
B_NO12
Output
Table 12
Module MR4
TERMINAL
SIGNAL
TYPE
DESCRIPTION
OPERATION
1
24VDC
-
24VDC power supply
-
4
0VDC
-
0VDC power supply
-
5
OSSD1_A
Input
Control ZONE 1
PNP active high
6
OSSD1_B
Input
7
FBK_K1_K2_1
Output
Feedback K1K2 ZONE 1
9
A_NC1
Output
NC contact ZONE 1
10
B_NC1
Output
13
A_NO11
Output
NO1 contact ZONE 1
14
B_NO11
Output
15
A_NO12
Output
NO2 contact ZONE 1
16
B_NO12
Output
11
A_NC2
Output
NC contact ZONE 2
12
B_NC2
Output
17
OSSD2_A
Input
Control ZONE 2
PNP active high
18
OSSD2_B
Input
19
FBK_K1_K2_2
Output
Feedback K1K2 ZONE 2
21
A_NO21
Output
NO1 contact ZONE 2
22
B_NO21
Output
23
A_NO22
Output
NO2 contact ZONE 2
24
B_NO22
Output
Table 13
