MODULAR SAFETY INTEGRATED CONTROLLER MOSAIC
8540780 • 25/01/2023 • Rev.43 89
Shows the
physical
address of the
unit
• Return the unit to ReeR to be repaired
• Firmware version not compatible with
MOSAIC M1, return to ReeR for FW upgrade.
Error in communication with
master
• Restart the system
• If the problem persists, return the unit to
ReeR to be repaired
Error on other
slave or MOSAIC M1
• Restart the system
• Check which unit is in FAIL mode
Same type of slave with same
address detected
• Change the unit's address (see NODE SEL)
Node detection circuit error
• Return the unit to ReeR to be repaired
Table 72 - Troubleshooting MI16
