Onboard Motion Sensor (Optional, -OC Models Only)
USER GUIDE
SPECIFICATIONS
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
ONBOARD MOTION SENSOR (OPTIONAL, -OC MODELS ONLY)
ONBOARD CARBON DIOXIDE SENSOR (OPTIONAL, -CO2 MODELS ONLY)
AUXILIARY INPUTS (OPTIONAL, -IO MODELS ONLY)
Type Passive Infrared Radiation (PIR)
Detection Distance 5 m (16” ft) maximum
Detection Angle 100° horizontal/82° vertical
Detection Zones 64
Type Non-dispersive infrared optical sensor
Range 0 – 2000 PPM
Resolution 1 PPM
Accuracy ±50 PPM
Calibration Automatic and/or manual
Quantity Two
Type Dry contact/10 k thermistor
Range -40 °C to 120 °C (-40 °F to 248 °F)
Resolution 0.1 °C (0.18 °F) below 90 °C (194 °F)
0.2 °C (0.36 °F) above 90 °C
Accuracy ± 1 °C (1.8 °F) below 90 °C (user calibrated to ± 0.1 °C)
± 1.5 °C (2.7 °F) above 90 °C
A/D Converter 12-bit
