INSTALLATION
SS
AND SS-L MODELS
TOOLS
In addition to the tools required for mounting the SMART-Sensor
™
, the following tools are
required:
FIGURE 24:
1
/16” FLEXIBLE ALLEN KEY (PM-ALLENKEY)
•
A flat-blade instrument screwdriver with 3 mm (
1
/8”) wide blade for wire terminal
screws, and
•
A
1
/16” Allen key for the Allen screws that secure the SS head to the backplate.
A flexible 1/16” Allen key designed to provide easy access to the Allen screws on the
backplate of the SS is available from Reliable Controls
®
using part number PM-ALLENKEY.
