SS-P MODELS
FIGURE 9: PHYSICAL DIMENSIONS (SS-P PICTURED)
The SS-P circuit board will fit into a back box or wall opening sized 3.73 x 6.85 cm (1
1
/2" x
2
3
/4") or greater.
6.99 cm
(2
3
/4”)
9.9 cm
(3
7
/8”)
11.43 cm
(4
1
/2”)
0.45 cm
(
3
/16”)
2.0 cm
(
13
/16”)
6.85 cm
(2
3
/4”)
3.73 cm
(1
1
/2”)
