FIGURE 8: BACKPLATE PHYSICAL DIMENSIONS (USED FOR SS/SS-L MODELS WITH -CO2 OPTION)
7.1 cm
(2
13
/16”)
1/2” wire grommet fits
two CAT5 cables.
12.1 cm
(4
3
/4”)
0.9 cm
(
3
/8”)
0.9 cm
(
3
/8”)
1.9 cm
(
3
/4”)
4.9 cm
(1
5
/16”)
8.3 cm
(3
1
/4”)
