PHYSICAL LAYOUT
SS-L MODELS
FIGURE 2: PHYSICAL LAYOUT (SS-L-OC, SS-L-D PICTURED)
Backplate
Sensor head
LCD screen (optional)
Optional occupancy sensor
Three-button keypad
X-Port-2
™
access port
Two 1.6 mm (
1
/16”) Allen screws
(secure sensor head to backplate)
Cooling vents
Sensor head
X-Port-2
™
converter access port
Optional Degrees C/F switch
