COMMAND BAR
The command bar is located along the bottom of the SMART-Sensor worksheet and has
six buttons as detailed in Table 13.
SMART-SENSOR SETUP DIALOG BOX
The SMART-Sensor Setup dialog box can be opened by clicking on the Setup button on
the SMART-Sensor worksheet command bar.
The fields of the SMART-Sensor Setup dialog box are detailed in Table 14.
TABLE 13: SSL WORKSHEET COMMAND BAR
Point Description
Mode
Used to toggle the worksheet between Update , Select and
Edit mode.
If the icon is displayed, values on the worksheet are static and
will not automatically refresh with current data. In this mode, any
field may be selected for modification.
If the icon is displayed, the vale in the field selected may be
edited. In this mode, data is not dynamically updated.
When the mode is toggled from mode or mode to mode,
the current configuration and entries in the worksheet are sent
from RC-Studio
®
2.0 to the controller. In this Update mode, current
data is loaded from the controller into the worksheet in
accordance with the RC-Studio
®
2.0 refresh rate.
Setup Opens the SMART-Sensor Setup dialog box (described later in
this section).
Print Prints the worksheet.
Erase Clears all worksheet entries and returns all fields to default values.
Abort Cancels all changes made to the worksheet since the last save
and reloads the configuration from the controller.
Close Closes the worksheet. If there are any unsaved modifications, the
user will be prompted to save the changes to the controller
