SMART-NET NETWORK TOPOLOGY
S
ENSORS PER CONTROLLER
The Reliable Controls
®
SMART-Sensor
™
is a networked sensor. SSs are interconnected
using SMART-Net
™
communication and networking. The maximum number of SSs that
may be connected to an individual SMART-Net
™
depends on the host controller.
SSs are daisy-chained, using either the RJ11 ports, or the terminal blocks provided. Any
mix of SS models may be installed on a single daisy chain. SMART-Sensor Enocean
Access Points
™
(SSEAs) can also be added to the mix, however each SSEA uses up two
addresses on a SMART-Net
™
.
Each SS (or SSEA) on a single SMART-Net
™
must have a unique address from 1 to a
maximum of 16. All SSs are shipped from the factory with a default address of 1.
TABLE 4: MAXIMUM SSS PER CONTROLLER
Controller SSs per Controller
MACH-Air/Zone
™
4
MACH-ProAir
™
4
MACH-ProZone
™
8
MACH-Pro1
™
8
MACH-Pro2
™
16
MACH-Stat
™
4
MACH1
™
8
MACH2
™
16
MACH-Global
™
16
MACH-Pro(Web)Com
™
16
MACH-Pro(Web)Sys
™
16
