INSTALLING MULTIPLE SSX EXPANSION BOARDS
TO INSTALL AND CONFIGURE MULTIPLE SSX EXPANSION BOARDS
1 Configure the SSX expansion board jumpers as required - EOL jumpers (A- &
B+), network jumpers (A- & B+), external power or SMART-Net
™
power.
2
Connect a rollover SS-VC from the host controller to the SMART-Net
™
port on the
first SSX.
3 Connect a rollover SS-VC from any of the PROG SENS ports on the first SSX to
the SMART-Net
™
port of the second SSX. Continue to daisy-chain subsequent
SSX expansion boards in this manner as required.
4 Connect the first SS to any free PROG SENS port on any SSX using a rollover
SS-VC.
5 Connect the second and subsequent SSs to the first SS using straight-through
SS-DCs between each SS.
6 Repeat steps 3, 4 and 5 as required.
A rollover Voice Cable (SS-VC) must be used whenever one end of the cable is plugged into
a port on a controller or SSX labelled SMART-Net
™
. Therefore, an SS-VC is required to
connect the first SSX to a controller, daisy-chained SSX expansion boards and the first SS
connected to an SSX or directly to a host controller.
A straight-through Data Cable (SS-DC) must be used only to connect one SS to another
SS.
