INSTALLING ONE SSX EXPANSION BOARD
TO INSTALL AND CONFIGURE ONE SSX EXPANSION BOARD
1 Configure the SSX expansion board jumpers as required (EOL jumpers,
network jumpers, and the power jumper).
2 Connect a rollover Voice Cable (SS-VC) from the host controller to the SMART-
Net
™
port on the SSX.
3 Connect the first SS to any of the PROG SENS ports on the SSX using a rollover
SS-VC.
4 Connect the second and subsequent SSs to the first SS using straight-through
Data Cables (SS-DC) between each SS.
5 Repeat steps 3 and 4 for the remaining SSs to be connected to the SSX.
Each SSX expansion board supports up to a maximum of 16 SSs. The use of an SSX
expansion board does not expand the maximum number of SSs supported by a specific
controller. Refer to Table 4 for the maximum number of SSs supported by each Reliable
Controls
®
MACH-System controller.
