Physical Layout
USER GUIDE
GETTING STARTED
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
SS MODELS
FIGURE 3: PHYSICAL LAYOUT (SS-CO2-UD AND SS-S PICTURED)
Optional Setpoint Buttons (SS-CO2-UD)
Optional Slider (SS-S)
Thicker backplate for -CO2 models
Two 1.6 mm (
1
/16”) Allen screws
(secure sensor head to backplate)
X-Port-2
™
converter access port
