SMART-Sensor Expansion Board (SSX)
USER GUIDE
SMART-NET NETWORK TOPOLOGY
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
The following diagram shows the optimal configuration for two SSX expansion boards
connected to a MACH-ProSys
™
controller with the maximum of 16 connect SSs.
FIGURE 23: FULLY-LOADED SMART-NET™ WITH 16 SS-LS AND TWO SSX EXPANSION BOARDS
MACH-ProSys
™
SSX
SS-Ls
rollover SS-VCs straight through
SS-DCs
SSX
straight through
SS-DCs
rollover SS-VCs
