Physical Dimensions
USER GUIDE
GETTING STARTED
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
SS-DUCT-GD MODELS
FIGURE 11: PHYSICAL DIMENSIONS (SS-DUCT-4-GD PICTURED)
F
IGURE 12: PHYSICAL DIMENSIONS (SS-DUCT-EH-RH PICTURED)
10.7 cm
(4
3
/16”)
5.0 cm
(2”)
5.9 cm
(2
5
/16”)
9.8 cm
(3
7
/8”)
7.8 cm
(3
13
/16”)
10.2, 15.2, 20.3, 30.5, 45.7 cm
(4, 6, 8, 12, or 18”)
10.16 cm
(4”)
9.68 cm
(3
13
/16”)
6.16 cm
(2
5
/8”)
2.7 cm
(1
1
/16”)
10.9 cm
(4
1
/4”)
Cover
To p V iew, N o C o ve r
Side View
19.68 cm
(7
3
/4”)
1.65 cm (
5
/
8
”)
1.91 cm (
3
/4”)
