9
Physical Dimensions
USER GUIDE
GETTING STARTED
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
FIGURE 7: STANDARD BACKPLATE PHYSICAL DIMENSIONS (USED FOR ALL SS/SS-L MODELS EXCEPT -CO2)
3.5 cm
(1
3
/8”)
1.3 cm
(
1
/2”)
3.0 cm
(1
3
/16”)
3.0 cm
(1
3
/16”)
8.2 cm
(3
1
/4”)
0.15 cm
(
1
/16”)
4.0 cm
(1
9
/16”)
7.0 cm
(2
3
/4”)
12.0 cm
(4
3
/4”)
