Wiring Details
USER GUIDE
INSTALLATION
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
FIGURE 43: CONNECTING TO MULTIPLE SS-LS
MACH-ProSys
™
Voice Cable (SS-VC)
rollover cable
Data Cable (SS-DC)
straight through cabl
e
