OCCUPANCY SENSOR OPTION (-OC)
SMART-SENSOR
™
 2004 – 2014 Reliable Controls
®
Corporation. All rights reserved.
Figure 72 illustrates the viewing angles within which the occupancy sensor can detect
motion.
FIGURE 72: MOTION DETECTION ANGLES
0°
50°
50°
0°
41°
41°
5 m
16 ft 5 in
2.5 m
8 ft 2 in
2.5 m
8 ft 2 in
5 m
16 ft 5 in
5 m
16 ft 5 in
2.5 m
8 ft 2 in
5 m
16 ft 5 in
2.5 m
8 ft 2 in
Plan View
Elevation View
