Electrics Section T
4 Remove
two
l-
UN F set screws, nuts,
lockwashers, and plain washers and detach
·u·
clamp securing motor
to
body. Remove motor,
carefully
withdrawing
cable rack from
wheelboxes and rack tubing.
5 Replace in reverse order, taking care not
to
damage cable rack.
Wheelboxes
and
cable
rack
tubing
To
remove
1 Disconnect battery.
2 From underneath fascia disconnect
speedometer cable.
3 Puff the fresh air nozzle from the
front
of
the fascia and disconnect
ducting
hose.
4
Withdraw
fascia (see
Section
R -
Interior)
just sufficiently
to
gain access
to
the
Wiper
motor
specification
Type
Typical
light
running current (i.e.
with
cable rack
disconnected) after
60
seconds
from
cold
Light running speed after
60
seconds from cold
Instruments and
switches
Speedometer
Located
to
the right
of
the steering wheel.
The meter indicates the speed
of
the
vehicle
and incorporates a total distance
travelled
recorder.
Direction
indicator
warning
light
An
amber light,
at
left
of
centre
on
the
speedometer face. While indicator flashing
unit
is in operation the warning lamp
glows
intermittently, in unison
with
the indicator
lamps.
Headlamp
main-beam
warning
light
A blue lamp, located at right
of
centre on the
speedometer face. The main-beam warning
lamp is illuminated
when
the headlamp beams
are raised and
will
go
out
when
the beams
are
dipped.
Water
temperature
and
fuel
gauge
This combined instrument is located
to
the left
of
the steering wheel and comprises
two
separate gauges. The upper segment
of
the
instrument indicates the cooling water
temperature in the engine.
After
the initial rise
in temperature during the
warming-up
period
a·ny
sudden upward change in the meter reading
calls
for
immediate investigation.
The
lower
segment
of
the instrument indicates
the quantity
of
fuel in the petrol tank. When the
wheelboxes and cable rack tubing.
It
is
not
necessary
to
disconnect instruments and
switches.
22
5 Detach
wiper
arms, remove wheelbox
spindle retaining nuts, spacers and washers and
push spindles through their locations in the
body.
6
Slacken L.H. wheelbox clamping nuts and
remove R.H. wheelbox, complete
with
intermediate and overrun
bundy
tube.
7 Remove R.H. wheelbox, complete
with
wheelbox
to
wiper
motor cable rack tubing.
8 Replace in reverse order.
Note:
Before fitting a
new
wheel box ensure
the drive wheel is
liberally coated
with
grease.
Lucas
14
watt
12
volt
1·5
amp
46-52
rev/min
ignition is switched on the indicator
will
slowly
rise
to
the final indicated reading due
to
the
damping
of
the meter mechanism.
Ignition
warning
light
The ignition warning
light
is located
to
the left
of
centre on the combined temperature and fuel
gauge. This red
light
serves the dual purpose
of
reminding the driver
to
switch
off
the ignition,
and
of
acting
as
a no-charge indicator. The
light
should
only
be illuminated
when
the
ignition is
switched
on
without
the engine
running, or running at very
low
speed.
When the engine speed is increased the
light
should dim and then
go
out, failure
to
do
so
indicates a fault in the charging circuit.
Oil
pressure
warning
light
The oil pressure warning light, green in colour,
is located
to
the right
of
centre on the
combined instrument. This
light
should
only
be
illuminated
when
the engine is at rest
with
the
ignition switched on. Immediately the engine
reaches speed
it
should extinguish, thus
indicating that the oil is circulating under
pressure.
Should the
light
come on
at
any other time stop
the engine immediately and investigate the
cause.
Battery
condition
indicator
gauge-
Super
models
only
Located to the left above the centre console this
