8
Fi
gure
7 Fitting rear cover
8 Remove seven bolts and
two
nuts,
complete
with
lo
ckwashers, and detach the
timing chain cover from the cylinder block.
7 Extract oil
se
al from cover u
si
ng tool
No
.
RT
7480
and
dr
ive handle part
No
. 550
(see Figure 8).
8
Fi
t
new
oil
sea
l, using
too
l No.
RT
7480
and drive handle, locating
as
shown in
Figure 9.
9 With the aid
of
centralising tool part
No
.
RT
7481
fit
the
timing
chain cover complete
with
gasket,
to
cylinder block, securing
with
seven bolts,
two
nuts and lockwashers (see
Figure
10
).
10
Replace crankshaft pulley, water pump,
refit fan be
lt
. and secure alternator.
Figure 8 Extracting front cover oil
sea
l
The engine
Figure
9 Replacing front cover oil
seal
11 Replace radiator, reconnect hoses and
refill the cooling system.
Operation
7-
Timing
chain
replacement
(with
front
cover removed)
1 Rel
ease
locking plate, unscrew
two
bolts,
remove camshaft sprocket and
lift
off
timing
chain. Retain camshaft sprocket locking plate.
2 Fit
new
timing chain
to
crankshaft and
camshaft sprocket
which
can be secured to
the camshaft, using the
lo
cking plate and
two
bolts.
Figure
10
Centralising front cover
