RL78/G13 CHAPTER 22 SAFETY FUNCTIONS
R01UH0146EJ0100 Rev.1.00 918
Sep 22, 2011
(2) Analog input channel specification register (ADS)
This register specifies the input channel of the analog voltage to be A/D converted.
Select ANIxx as the target of A/D conversion by ADTS register when converting the internal reference voltage (1.45
V), and specify the internal reference voltage output as the input source in the analog input channel specification
register (ADS).
The ADS register can be set by a 1-bit or 8-bit memory manipulation instruction.
Reset signal generation clears this register to 00H.
Figure 22-16. Format of Analog Input Channel Specification Register (ADS) (1/2)
Address: FFF31H After reset: 00H R/W
Symbol 7 6 5 4 3 2 1 0
ADS ADISS 0 0 ADS4 ADS3 ADS2 ADS1 ADS0
{ Select mode (ADMD = 0)
ADISS ADS4 ADS3 ADS2 ADS1 ADS0 Analog input
channel
Input source
0 0 0 0 0 0 ANI0 P20/ANI0/AVREFP pin
0 0 0 0 0 1 ANI1 P21/ANI1/AVREFM pin
0 0 0 0 1 0 ANI2 P22/ANI2 pin
0 0 0 0 1 1 ANI3 P23/ANI3 pin
0 0 0 1 0 0 ANI4 P24/ANI4 pin
0 0 0 1 0 1 ANI5 P25/ANI5 pin
0 0 0 1 1 0 ANI6 P26/ANI6 pin
0 0 0 1 1 1 ANI7 P27/ANI7 pin
0 0 1 0 0 0 ANI8 P150/ANI8 pin
0 0 1 0 0 1 ANI9 P151/ANI9 pin
0 0 1 0 1 0 ANI10 P152/ANI10 pin
0 0 1 0 1 1 ANI11 P153/ANI11 pin
0 0 1 1 0 0 ANI12 P154/ANI12 pin
0 0 1 1 0 1 ANI13 P155/ANI13 pin
0 0 1 1 1 0 ANI14 P156/ANI14 pin
0 0 1 1 1 1 Setting prohibited
0 1 0 0 0 0 ANI16 P03/ANI16 pin
Note 1
0 1 0 0 0 1 ANI17 P02/ANI17 pin
Note 2
0 1 0 0 1 0 ANI18 P147/ANI18 pin
0 1 0 0 1 1 ANI19 P120/ANI19 pin
0 1 0 1 0 0 ANI20 P100/ANI20 pin
0 1 0 1 0 1 ANI21 P37/ANI21 pin
0 1 0 1 1 0 ANI22 P36/ANI22 pin
0 1 0 1 1 1 ANI23 P35/ANI23 pin
0 1 1 0 0 0 ANI24 P117/ANI24 pin
0 1 1 0 0 1 ANI25 P116/ANI25 pin
0 1 1 0 1 0 ANI26 P115/ANI26 pin
0 1 1 0 1 1 Setting prohibited
1 0 0 0 0 0 − Temperature sensor output
1 0 0 0 0 1 − Internal reference voltage
output (1.45 V)
Other than the above Setting prohibited
(Notes and cautions are listed on the next page.)
