Rexroth Indramat DURADRIVE SYSTEM200 User Manual

1-4 Introduction to the system DURADRIVE Drive Controllers
DOK-DURADR-HDC01.1****-PR02-EN-P
1.3 An overview of the drive controllers
Type code for drive controller HDC
HDC 01.1 - A040N - PB01 - 01 - FW
Line 01
Product group HDC
Type code fields:
Example:
Special design
none N
Rated current
40 A 040
100 A 100
200 A 200
Design 1
TL0214F1.FH7
Cooling mode
natural convection (heatsink
outside) A
Firmware FW
denotes that firmware must be ordered as separate
subposition = FW
Interface
CANopen interface CN01
DeviceNet interface DN01
InterBus interface IB01
Profibus-DP interface PB01
SERCOS interface SE01
SERCOS interface 2 SE02
Version of the interface 01
Fig. 1-3: Type code HDC
Type code for cooling fan unit
Class: Drive controller HDC H
Product: Cooling fan unit for controllers LEC
Other design
none N
TL0216F1.FH7
LECH - 040N
Type code fields:
Example:
Rated current for drive controller
40 A 040
100 A, 200 A 200
Fig. 1-4: Type code cooling fan unit
Note: The above illustrates how the type codes are put together.
Your Sales rep will help with the current status of available
versions.
