4-14 DURADRIVE HDC01.1 Drive Controller DURADRIVE Drive Controllers
DOK-DURADR-HDC01.1****-PR02-EN-P
Storable energy in the bus
Note: The higher the connection voltage the lower the energy that
can be stored in the DC bus as the differential voltage
between bleeder threshold and DC bus voltage (threshold
value of connecting voltage) decreases.
30
40
50
60
70
80
90
100
110
120
130
140
150
160
170
180
150200250300350400450500550
U
N1
[V]
W
ZW
[Ws]
W
ZW
: Storable energy of the DC bus capacitors
U
N1
: Mains input voltage
Fig. 4-17: Storable energy in the bus HDC01.1-A040N
