DURADRIVE Drive Controllers Replacing or Exchanging Drive Components 11-3
DOK-DURADR-HDC01.1****-PR02-EN-P
11.2 Procedure on Replacing the Unit
Note: Note the safety instructions in section 2 when exchanging any
parts!
Replacing the drive controller:
• Make sure the drive controller is completely de-energized.
• Switch main switch off.
• Secure against being switched back on.
DANGER
Lethal electric shock caused by charged
capacitor!
⇒ Prior to touching bear connecting cables and
terminals, wait for the capacitor to discharge! Only
then work on the cables!
• Open cable bushing (see page 4-7) and loosen cable at the drive
controller.
• Remove contact protection and separate connecting line from the
drive controller.
• Release screws on top and bottom of housing.
• Remove the drive controller.
• Insert programming module from defective drive controller into new
one. This eliminates the reloading of parameter files. If the
programming module is defective, see section "Replacing Firmware".
• Hand new drive controller into place and tighten screws.
• If existing, replace cooling fan unit (see chapter 9-3).
• Connect drive controller as specified in the machine terminal
diagrams.
• Close cable bushing (see page 4-7).
• Start up installation.
