DURADRIVE Drive Controllers Replacing or Exchanging Drive Components 11-5
DOK-DURADR-HDC01.1****-PR02-EN-P
• Put the cooling fan unit on the drive controller and turn the connector
in such a way that it fits into connector X14 at the drive controller.
• Close the bayonet joint of connector X14.
• By turning the ball handle screw, screw the cooling fan unit down to
the drive controller.
Note:
• The cooling fan unit is monitored by the drive controller. If the number
of revolutions falls below a minimum value, there is an alarm
message.
• Drive controller HDC01.1-A040N: After the cooling fan unit has been
mounted and the drive controller switched on again, the respective
parameters of the drive controller are switched automatically.
• Drive controllers HDC01.1-A100N and HDC01.1-A200N: If the
ventilator has not been mounted, there is an error message.
Dismounting
Note: Only dismount the cooling fan unit when the drive controller
has been switched off.
• Switch off the drive controller completely.
• Loosen the ball handle screw.
• Open the bayonet joint of the connector.
• Remove the cooling fan unit.
• Put the cover on connector X14.
