• Replace cables
• Connect plug-in connectors
Switchboard wallMachine housing
V2 V2 V2 V2 V2
Motor
V2
Immediate environment requirements
Conductive contamination cannot occur when operating the control
drive (at least not with the IP 65); when installing or exchanging drive
components, non- conductive contamination or light condensation
may momentarily occur.
AP5381F1.Fh7
Drive controller
Fif. 11-3: Dirt contamination per DIN VDE 0160
ATTENTION
Property damage caused by bad power
connectors!
⇒ Connect power connections only when they are dry
and clean.
