Note: The input 0V is connected directly to the device potential. The
utilisation of an insulation monitoring for +24V and 0V against
device is therefore not possible!
wire cross section: min. 1 mm²
wire routing: parallel if possible
Max. allowed inductance between 24V source
and X1:
100µH
(equals about 2 x 75m)
Note:
• Exceeding allowed control voltage generates error message "+24 volt
error". (=> See also firmware functional description.).
• Control voltage failure causes the running motor to coast torque-free
(without brake).
DANGER
Dangerous movements due to unbraked
coasting of motor with control voltage failure!
⇒ Personnel should not remain within the area of the
machine with moving parts. Possible preventive
steps against unauthorized access are:
– protective fencing
– bars
– covers
– light barriers.
⇒ The fences must be able to withstand the maximum
possible force that the machine can generate.
wire
+24V and 0V
