4-62 DURADRIVE HDC01.1 Drive Controller DURADRIVE Drive Controllers
DOK-DURADR-HDC01.1****-PR02-EN-P
AP5377F1.FH7
1
6
2
3
4
5
7
Fig. 4-111: Ventilator connection
Type No. of pins Design
Circular connector 7 Pins on unit
Fig. 4-112: Design
Design
