Ricoh Aficio MP 301SPF Service Manual

Bit Switches
D127/D128 5-64 SM Appendix
4-5
Modem setting for transmission
Sets the modem for transmission.
The default is "00" (V29).
Bit 5: 0, Bit 4: 0 = V29
Bit 5: 0, Bit 4: 1 = V17
Bit 5: 1, Bit 4: 0 = Not used
Bit 5: 1, Bit 4: 1 = Not used
*V34 is not supported for IP-Fax communication.
6-7 Not used Do not change these settings.
IP Fax Switch 06 [SP No. 1-111-007]
No. FUNCTION COMMENTS
0-3
Modem bit rate setting for reception
Sets the modem bit rate for reception. The default is "0110" (14.4K bps).
Bit 3 Bit 2 Bit 1 Bit 0
0 0 0 1 2400 bps
0 0 1 0 4800 bps
0 0 1 1 7200 bps
0 1 0 0 9600 bps
0 1 0 1 12.0 Kbps
0 1 1 0 14.4 Kbps
0 1 1 1 Not Used
1 0 0 0 Not Used
1 0 0 1 Not Used
1 0 1 0 Not Used
1 0 1 1 Not Used
1 1 0 0 Not Used
1 1 0 1 Not Used

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
