Ricoh Aficio MP 301SPF Service Manual

Bit Switches
SM Appendix 5-65 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
1 1 1 0 Not Used
4-7
Modem setting for reception
Sets the modem type for reception. The default is "0100" (V27ter, V29, V17).
Bit 7 Bit 6 Bit 5 Bit 4
0 0 0 1 V27ter
0 0 1 0 V27ter, V29
0 0 1 1
V27ter, V29, V33
(invalid)
0 1 0 0 V27ter, V29, V17
0 1 0 1 Not Used
*V34 is not supported for IP-Fax communication.
IP Fax Switch 07 [SP No. 1-111-008]
No. FUNCTION COMMENTS
0
TSI information
0: Not added, 1: Added
Adds or does not add TSI information to
NSS(S).
1
DCN transmission setting at T1
timeout
0: Not transmitted,
1: Transmitted
Transmits or does not transmit DCN at T1
timeout.
2 Not used Do not change this setting.
3
Hang up setting at DIS reception
disabled
0: No hang up
1: Hang up after transmitting DCN
Sets whether the machine disconnects after
DIS reception.
4
Number of times for training
0: 1 time, 1: 2 times
Selects the number of times training is done
at the same bit rate.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
