Ricoh Aficio MP 301SPF Service Manual

Bit Switches
SM Appendix 5-67 D127/D128
Appendix:
Fax Trouble-
Shooting
Guide
IP Fax Switch 09 [SP No. 1-111-010]
No. FUNCTION COMMENTS
0
Setting IPv4 or IPv6 for SIP call
connection
0: IPv4 (Default)
1: IPv6
This function is used to make SIP connection
suited to the user network environment.
1
Setting the way to choose the
method with which FAX data
communication is done
0: The same method as the call
connection
1: Automatic setting
Sets selection way of network I/F method
Automatic setting (1) means negotiating with
call connection before determining IPv4 or
IPv6.
2
Record-route using
1: Enabled
2: Disabled
“Enabled” is for Record-route acceptable SIP
server
3-4
Delay time between
ACK-message reception and
re-INVITE transmitting
Set this function more than “1 sec” when SIP
connection is done via HiPath8000/4000
(Siemen Co.)
Bit 3 Bit 4
0 0 No delay
1 0 1 sec
0 1 2 sec
1 1 3 sec
5-7 Not used Do not change these settings.

Ricoh Aficio MP 301SPF Specifications

Power

power requirements	120V, 60Hz, 8A
power consumption	Less than 1.1 kW
sleep mode power consumption	2.8 W

System Memory

system memory	1 GB RAM
hard disk drive	Optional 128 GB HDD
CPU	RM7035C – 533 MHz

Printer Specifications

output speed	Up to 31 ppm (Letter)
maximum print resolution	600 x 600 dpi
first copy time	6 seconds or less

Paper Handling

standard input capacity	250 sheets + 100-Sheet Bypass Tray
output capacity	250 sheets (internal tray)
document feeder original capacity	50 sheets (ARDF)

Scanner Specifications

scanning speed	31 ipm @ 300 dpi B/W
scanning resolution	100 to 600 dpi
scan area main	8.5 inches

Weight and Dimensions

width	19.0 inches
depth	17.7 inches
height	18.1 inches
weight	57.3 lbs.
