Ricoh Aficio MP C5502 User Manual

When the paper that is loaded is the same size and orientation as the original, the relationship
between the orientation in which you place the original and the punch hole positions is as follows.
You can confirm the punch hole positions that can be selected on the screen that appears when
[Finishing] is pressed.
Placing the original on
the exposure glass
Placing the original in the
ADF
Punch hole position
*1
2 hole left
*2
2 hole top
*3
*2 *3
3 hole left
*2
3 hole top
*3 *2 *3
4 hole left
*2
4 hole top
*3 *2 *3
*1
The above table shows punch hole positioning. Punched sheets might not be delivered in the orientation
shown in this table.
*2
You cannot punch holes in this position when copying onto B4 JIS, 8 × 13 or larger, or 5
1
/
2
× 8
1
/
2
.
*3
If you want to punch holes in this position, select unreadable orientation in [Original Orientation], and
then select the punch hole position.
3. Copy
84

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
