Ricoh Aficio MP C5502 User Manual

6. Save the configuration file that has been edited.
Installing the LAN-FAX driver in "Add Printer"
Install the LAN-FAX driver after the configuration file has been edited.
1. Open the printer window.
• Windows XP, Windows Server 2003:
On the [Start] menu, select [Printers and Faxes].
•
Windows Vista, Windows Server 2008:
On the [Start] menu, select [Control Panel], and then click [Printers] in [Hardware and Sound]
category.
• Windows 7, Windows Server 2008 R2:
On the [Start] menu, select [Devices and Printers].
2. Click [Add Printer] or [Add a printer].
3. Click [Add a local printer].
4. Select the port.
• To use the same port as the printer drive:
1. Click [Use an existing port:].
2. Select the same port as the one selected in the printer driver from the [Use an existing
port:] list.
3. Click [Next].
• To use another Standard TCP/IP port:
1. Click [Create a new port:].
2. Select [Standard TCP/IP Port] in the [Type of port:] list.
3. Click [Next].
4. Enter the machine name or IP address in the [Hostname or IP address:] box.
5. Click [Next].
5. Select the manufacturer and model name of the machine you want to use, and then click
[Next].
6. Change the machine name if you want, and then click [Next].
The installation starts.
7. Follow the instructions that appear. Modify settings such as the default printer and printer
sharing configuration, as necessary. You can also print a test page.
Enabling the Function to Prevent Transmission to the Wrong Destination
45

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
