Ricoh Aficio MP C5502 User Manual

Parallel Connection
To use a printer connected using a parallel interface, click [LPT1] when installing the printer driver.
1. Quit all applications. (Do not close this manual.)
2. Insert the provided CD-ROM into the computer's CD-ROM drive.
If the [AutoPlay] dialog box appears, click [Run AUTORUN.EXE].
3. Select an interface language, and then click [OK].
For details about the languages supported in the printer drivers, see p.6 "Supported languages".
4. Click [PCL Printer Drivers] or [PostScript 3 Printer Driver].
5. The software license agreement appears in the [License Agreement] dialog box. After
reading the agreement, click [I accept the agreement.], and then click [Next].
If installing the PostScript 3 printer driver, proceed to step 7.
6. Select a printer driver you want to use, and then click [Next].
7. Select the check box of the machine model you want to use.
8. Double-click the machine name to display the printer settings.
9. Click [Port :].
10. Select [LPT1:] in the [Change settings for 'Port'] drop-down list.
11. Configure the user code, default printer, and shared printer as necessary.
12. Click [Continue].
The installation starts.
13. Click [Finish].
Select one of the options to restart the computer either now or later, and then click [Finish].
Bluetooth Connection
• The Bluetooth unit and the optional wireless LAN unit cannot be used simultaneously.
Supported profiles and restrictions
Supported Profiles
• SPP (Serial Port Profile)
•
HCRP (Hardcopy Cable Replacement Profile)
• BIP (Basic Imaging Profile)
Installing the Printer Driver for a Local Connection
31

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
