Ricoh Aficio MP C5502 User Manual

Loading Paper into Tray 3 (LCT)
• When paper loaded in the right side of Tray 3 (LCT) runs out, paper on the left is automatically
shifted to the right. Do not pull out Tray 3 (LCT) while the tray is moving paper; wait until sounds
stop coming from the tray.
• For the right stack, align the right edge of the paper with the right edge of the tray. For the left
stack, align the left edge of the paper to the left edge of the tray.
• (mainly Europe and Asia)
Tray 3 (LCT) can hold A4 paper only. If you want to print on 8
1
/
2
× 11 from Tray 3 (LCT),
contact your service representative.
• (mainly North America)
Tray 3 (LCT) can hold 8
1
/
2
× 11 paper only. If you want to print on A4 from Tray 3 (LCT),
contact your service representative.
1. Carefully pull out Tray 3 (LCT) until it stops.
CJW015
2. Square the paper and load it print side up.
Do not stack paper over the limit mark.
• Whole tray pulled out
CJW016
9. Adding Paper and Toner
144

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
