Configuring IEEE 802.1X Authentication
IEEE 802.1X is an authentication function that can be used with both wired and wireless networks.
Authentication is performed by the authentication server (RADIUS server).
You can select four types of EAP authentication method: EAP-TLS, LEAP, EAP-TTLS and PEAP. Note that
each EAP authentication method has different configuration settings and authentication procedures.
Types and requirements of certificates are as follows:
EAP type Required certificates
EAP-TLS Site certificate, Device certificate (IEEE 802.1X Client Certificate)
LEAP -
EAP-TTLS Site certificate
PEAP Site certificate
PEAP (Phase 2 is for TLS
only)
Site certificate, Device certificate (IEEE 802.1X Client Certificate)
Installing a Site Certificate
Install a site certificate (root CA certificate), which checks the reliability of the authentication server. You
need to have at least a certificate that is signed by a certificate authority who signed the server certificate
or a certificate from an upper level certificate authority.
1. Log in as the network administrator from Web Image Monitor.
2. Point to [Device Management], and then click [Configuration].
3. Click [Site Certificate] under "Security".
4. Click [Browse] on the "Site Certificate to Import" window, and then select the CA
certificate you obtained.
5. Click [Open].
6. Click [Import].
7. Check that the imported certificate's [Status] shows "Trustworthy".
If [Site Certificate Check] shows [Active], and the [Status] of the certificate shows [Untrustworthy],
communication might not be possible.
8. Click [OK].
9. Log out.
5. Enhanced Network Security
174

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
