Ricoh Aficio MP C5502 User Manual

1. Press [Select Stored File].
2. Select the documents to be sent.
When multiple documents are selected, they are sent in the order of selection.
• Press [User Name] to place the documents in order by programmed user name.
•
Press [File Name] to place the documents in alphabetical order.
• Press [Date] to place the documents in order of programmed date.
• Press [Queue] to arrange the order of the documents to be sent.
To view details about stored documents, press [Details].
Press the Thumbnails key to switch the screen to thumbnail display.
3. If you select a document with a password, enter the password using the number keys,
and then press [OK].
4. When you want to add your originals to stored documents and send them all at once,
press [Original ]
[ Stored File] or [Stored file ] [ Original].
When [Original ] [ Stored File] is pressed, the machine sends the originals, and then stored files.
When [Stored file ] [ Original] is pressed, the machine sends the stored files, and then originals.
5. Press [OK].
6. To add an original to stored documents, place the original, and then select any scan
settings you require.
7. Specify the destination, and then press the [Start] key.
Storing a Document
99

Ricoh Aficio MP C5502 Specifications

General

Functions	Print, Copy, Scan, Fax
Print Technology	Laser
Max Print Resolution	1200 x 1200 dpi
Copy Resolution	600 x 600 dpi
Multiple Copy	Up to 999 copies
Max Paper Capacity	4, 400 sheets
Duplex Printing	Yes
Hard Disk Drive	250 GB
Power Consumption (Maximum)	1.7 kW
Type	All in One Printer
Print Speed	55 pages per minute
Copy Speed	55 copies per minute
Zoom	25% to 400%
Scan Resolution	600 dpi
Fax Resolution	200 x 200 dpi
Original Capacity	100 sheets
Standard Paper Capacity	1, 200 sheets
Memory	1.5 GB RAM
Interface	USB 2.0, Ethernet
Network Protocols	TCP/IP
Operating Systems Supported	Windows, Mac, Linux
Power Source	AC 120V, 60Hz
Paper Weight	52 – 256 g/m²
